| Model | T30A | |||||
| Specs Options | T30ABMS/T30ABML/T30AFWS/T30AFWL/T30ABWS/T30ABWL | |||||
| Max. Output Power | 30HP(22KW) | |||||
| Transom height | 15/20in. | |||||
| Dry Weight | 52-57.5kg | |||||
| Max. RPM Range | 4500～5500r/min | |||||
| Idling RPM Range | 1050～1150r/min | |||||
| Engine Type | 2-cyl. | |||||
| Displacement | 496cc | |||||
| Bore×Stroke | 72.0×61.0mm | |||||
| Ignition System | CDI | |||||
| Steering System | Tiller/Remote Control | |||||
| Starting System | Manual or Electric | |||||
| Gear Shift | F-N-R | |||||
| Gear Ratio | 2.08 | |||||
| Trim & Tilt | Manual | |||||
| Fuel Tank Capacity | 24L | |||||
| Max. Fuel Consumption | 12L/h | |||||
| Lubrication System | 50:1 | |||||
| Gear Oil Capacity | 320cc | |||||
| Propeller | 11" or 12" | |||||
Parameter description:
The propeller choice will vary by boat size and application.
B=Back Control(Tiller controk), F=Front control(Remote control), M=Manual start, S=Short shaft, L=Long shaft, W=Manual starting and electric starting
